Taidacent Industrial Small Endoscope Medical Camera Module 720P HD Endoscope Camera USB Free Driver Endoscope CMOS Camera Module

Product Description

Mainly used in industry, medical endoscopy, smart phones, PC multimedia, etc.

Specification

item	value
active array size	1280x 720
power supply	analog: 2.6 ~ 3.0V (2.8V normal) core: 1.2VDC±5% I/O: 1.8V
power requirements active	active: 69 mW
temperature range	operating: -30°C to 85°C junction temperature stable image: 0°C to 50°C junction temperature
output formats	10-bit Raw RGB
lens size	1/9"
lens chief ray angle	32.1°
input clock frequency	6~27 MHz
scan mode	progressive
sensitivity	585 mV/Lux-sec
shutter	rolling shutter
max S/N ratio	36.4 dB
dynamic range	68.4 dB @ 16x gain
maximum exposure	interval 798 X tRow
pixel size	1.4μmx1.4 um
dark current	2e - /sec at 50°C junction temperature
image area	1819.58 umx 1033.34 um
