Share
Details of burner
Safety: auto ignitor
Safety : auto add fuel
Product Application
72 inch intelligent ethanol burner
|
SPECIFICATIONS FOR 25 TON CRAWLER EXCAVATOR
|
||||||
|
Size
|
1829mm L x 193mm W x 168mm H
|
Function
|
1. Automatic ignition/extinction
|
|||
|
Flame length
|
1701mm L
|
2. With electronic heat detectors
|
||||
|
Material
|
304# stainless steel
|
3. With heavy shake sensor
|
||||
|
Capacity
|
20 liters
|
4. Auto-filling fuel
|
||||
|
Fuel Consumption
|
0.8~2.3 L/H
|
5. Flame adjustment
|
||||
|
Heat output
|
5300W~15000W
|
6. CO2 density alarm
|
||||
|
Packing size
|
201*30*32CM H
|
7. Anti-interference
|
||||
|
G.W.
|
47kg
|
Optional WIFI control:
|
||||
|
Hole size for fit burner in
|
1824mm L x 180mm W x 250mm H
|
Option smart home dry contact
|
||||
|
Technical data as follow:
|
Option children lock
|
|||||
|
Voltage:
|
100V~240V
|
|
||||
|
Inside burner:
|
DC 24V/2A
|
|||||
|
Frequentie:
|
50HZ/60HZ
|
OPtion Linkage function
|
||||
|
Electrical consumption:
|
50W
|
|||||
Main Features
1. Automatic ignition/extinction, control by a Button ON/OFF and remote control.
2. AC adaptor.
More safety:
1. Save the ethanol fuel in a separate tank which away from the burning chamber.
2. With electronic heat detectors ,it will automatice extinction when the temperature reaching the un-authorized levels.
3. With heavy shake sensor, flame will be distinguished automatically when fireplace body turn over or shake.
4. Auto-filling fuel by press a botton, let your handle free.
5. Flame adjustment- 4 flame size available
6. CO2 density alarm.
Material: 3mm thickness 304#stainless steel top plate ,1.2mm thickness 304#stainless steel side, bottom and tank
Technical data:
Voltage: 100V~240V Inside burner: DC 24V/2A
Frequentie: 50HZ/60HZ
Electrical consumption: 50W
Machine Parts
Name:filling mouth
Brand: inno fire
Original: China
Main Features
Name: part of fireplace
Brand:inno fire
Original: China
Machine Parts
Name: ignitor of burner
Brand: inno fire
Original: China
