ATNJ Dual Band 900/2100 Cellphone Signal Enhancer Booster Repeater Amplifier

Write a review

Save -55% Rs. 220,631.55 ~~Rs. 487,802.57~~

Brand : Shanvis

Collection : Mobiles & Accessories

SKU : 6087907013089_96027572

Availability : 999 In Stock Sold Out 999

HURRY ! ONLY 999 LEFT IN STOCK.

Specification520*240*160mm

Translation missing: en.products.product.product_variants

Quantity

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Security

FREE SHIPPING

WORLDWIDE

BIG SAVING ON

WEEKENDS

24H SUPPORT

Description
Shipping

Product Description

Features:

1,Intelligent to guide the installation with LCD
2,Real time display the signal strength.
3,Automatic dormancy when no user make the calling
4,Automatic alarm when installation mistake and provide the according solution
5,Automatic adjust the system gain to avoid the repeater self-excitation
6,initiative reminding when the device was damaged.

Specification

SPECIFICATIONS			parameters
Frequency Range (Customers to Choose)	Uplink	890-915MHz,1920-1980MHz
Frequency Range (Customers to Choose)		Downlink	935-960MHz,2110-2170MHz
Frequency Bandwidth (3dB Bandwidth)			35MHz
Gain			90dB
Automatic gain control (Step Attenuation)			31dB @ 1dB/ Step
Auto Gain Control			30dB Min.
Output Power(Customers to Choose)			33dBm
Spurious Emission			≤ -15dBm/30kHz
				9kHz~1GHz: ≤ -36dBm/30kHz
				1GHz~12.75GHz: ≤ -30dBm/30kHz
Inter-Modulation Attenuation ACPR			≤ -40dBc / 30kHz (measured under rated output power)
In-band Ripple			≤ 3dB
VSWR			<=2
I/O Impedance			50 Ω
Noise Figure			≤ 5dB
System Delay			≤ 5μs
RF Connector(Customers to Choose)			N (Female)
Operating Temperature			Operation: - 10°C ~ + 55°C / Storage: -20°C ~ +60°C
Power Supply			AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A power adapter)
Dimensions			16513040 (mm)
Weight			≤5kg(Net)
Indication LED			Power supply
