Product Description
Hybrid Inverter
An on-grid inverter’s main job is to convert DC power generated from the PV array into usable AC power. Hybrid inverters go a step further and work with batteries to store excess power as well. In the developing world, hybrid inverters are more of a necessity to compensate for weak or intermittent grids or a lack of grid electricity all together.
Specifications
|
Model
|
SUN-3.6K-SG03LP1-EU
|
SUN-5K-SG03LP1-EU
|
SUN-6K-SG03LP1-EU
|
|||
|
Battery Input Data
|
||||||
|
Battery Type
|
Lead-acid or Lithium-ion
|
|||||
|
Battery Voltage Range (V)
|
40~60V
|
|||||
|
Max. Charging Current (A)
|
90A
|
120A
|
135A
|
|||
|
Max. Discharging Current (A)
|
90A
|
120A
|
135A
|
|||
|
Charging Curve
|
3 Stages / Equalization
|
|||||
|
External Temperature Sensor
|
Optional
|
|||||
|
Charging Strategy for Li-Ion Battery
|
Self-adaption to BMS
|
|||||
|
PV String Input Data
|
||||||
|
Max. DC Input Power (W)
|
4680W
|
6500W
|
7800W
|
|||
|
PV Input Voltage (V)
|
370V (125V~500V)
|
|||||
|
MPPT Range (V)
|
150~425V
|
|||||
|
Full Load DC Voltage Range
|
300~425V
|
|||||
|
Start-up Voltage (V)
|
125V
|
|||||
|
PV Input Current (A)
|
13A+13A
|
|||||
|
Max. PV ISC (A)
|
17A+17A
|
|||||
|
No.of MPPT Trackers
|
2
|
|||||
|
No.of Strings Per MPPT Tracker
|
1
|
|||||
|
AC Output Data
|
||||||
|
Rated AC Output and UPS Power (W)
|
3600W
|
5000W
|
6000W
|
|||
|
Max. AC Output Power (W)
|
3690W
|
5500W
|
6600W
|
|||
|
Peak Power (off grid)
|
2 times of rated power, 10 S
|
|||||
|
AC Output Rated Current (A)
|
16.4/15.7
|
22.7/21.7
|
27.3/26.1
|
|||
|
Max. AC Current (A)
|
18/17.2
|
25/23.9
|
30/28.7
|
|||
|
Max. Continuous AC Passthrough (A)
|
35A
|
40A
|
||||
|
Power Factor
|
0.8 leading to 0.8 lagging
|
|||||
|
Output Frequency and Voltage
|
50/60Hz; 220/230 / 240Vac (single phase)
|
|||||
|
Grid Type
|
Single Phase
|
|||||
|
Current Harmonic Distortion
|
THD<3% (Linear load<1.5%)
|
|||||
Deye full series inverter
Hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and
increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads
initially. Then, the excess energy will charge the battery via solar inverter. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout. It equipped with RS485/CAN port for battery communication
Hybrid inverter, is suitable for residential and light commercial use, maximizing self-consumption rate of solar energy and
increasing your energy impendence. During the day, the PV system generates electricity which will be provided to the loads
initially. Then, the excess energy will charge the battery via solar inverter. Finally, the stored energy can be released when the loads require it. The battery can also be charged by the diesel generator to ensure uninterrupted supply in the event of grid blackout. It equipped with RS485/CAN port for battery communication
Features:
* Colorful touch LCD, IP65 protection degree
* 6 time periods for battery charging/discharging
* Max. charging/discharging current of 190A
* Max.16pcs parallel
* DC couple and AC couple to retrofit existing solar system
* Support storing energy from diesel generator
* 48V low voltage battery, safe and reliable
* Unique Smart Load application and Grid peak shaving function
* 4ms fast transfer from on-grid to off-grid mode, ensuing the traditional fixed frequency air conditioner works well
* Colorful touch LCD, IP65 protection degree
* 6 time periods for battery charging/discharging
* Max. charging/discharging current of 190A
* Max.16pcs parallel
* DC couple and AC couple to retrofit existing solar system
* Support storing energy from diesel generator
* 48V low voltage battery, safe and reliable
* Unique Smart Load application and Grid peak shaving function
* 4ms fast transfer from on-grid to off-grid mode, ensuing the traditional fixed frequency air conditioner works well
