electric bicycle motor OEM 24v/36v/48v E bike battery
Share
1. Model: XTY-S-24120
2. Type: Li-ion battery with PCM
3. Nominal voltage: 24v/36v/48v or OEM
4. Typical capacity: 10Ah/15Ah/20Ah/25Ah/30Ah or OEM
5. Internal Impedance(1kHz AC): <250mΩ
6. Max Charge voltage: 29.4±0.05V
7. Discharger cut-off voltage: 21±0.05V
8. Max charge current: 2A
9. Max continuous discharge current: 24A
10. Max pulse discharge current: 36A (2 s)
11. Charging temperature: 0°C~45°C
12. Discharging temperature: -20°C~60°C
13. Storage temperature: -20°C~45°C
14. About 500 cycles to 80% with 100% DOD under: 20 °C~25°C
15. Size(L*W*H): 385*87*88mm
16. Weight: approx.2.2Kg
17. Application: E-bike, E-motor, E-scooter, UPS, E-wheelchair, Vacuum cleaner etc.
18. Hard case: silver fish case, rear rack case, water bottle case
II.Compared with SLA battery,li-ion battery has many advantages:
1.Long cycle life: up to 500 times
2.Green: Non-Toxic, comfort to RoHS.
3.Safety
The safest battery in the world till now, which does not burn with 30V charge and it does not explode when you puncture the battery. CE approved.
4.Light weight and smaller dimension
The dimension is smallest and the weight is lightest when compare with other battery. 1/3 weight of SLA, 65% weight of NIMH.
5. Great capacity and more powerful, rechargeable battery
High discharge current, 1C continuous, 3C pulse for normal cells and 20 C for special design
We can install many single cells in series and in parallel and it can fully discharge
6. Good thermal stability: - 20°C to 60°C
7. Back fast charge, good consistence, no memory effect, can equip battery charger.
Can be recharged anytime, no reduction of the capacity
8.Widely application, customize solutions, mass production, OEM/ODM/buyer label provided
