ESG stock Growatt Inverter SPF 5000ES 5000W 3500W 48vdc 5000VA 5KW Wifi Monitoring Off Grid Solar Inverter
Share
Growatt Inverter SPF 5000ES 5000W 3500W 48vdc 5000VA 5KW Wifi Monitoring Off Grid Solar Inverter
Why choose us?
Why choose us?
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
| Datasheet | SPF 3500 ES | SPF 5000 ES |
| Battery Voltage | 48VDC | |
| Battery Type | Lithium/Lead-acid | |
| INVERTER OUTPUT | ||
| Rated Power | 3500VA/ 3500W | 5000VA/ 5000W |
| Parallel Capability | Yes, 6 units maximum | |
| AC Voltage Regulation (Battery Mode) | 230VAC ± 5% @ 50/60Hz | |
| Surge Power | 7000VA | 10000VA |
| Efficiency (Peak) | 93% | |
| Waveform | Pure sine wave | |
| Transfer Time | 10ms typical, 20ms Max | |
| SOLAR CHARGER | ||
| Maximum PV Array Power | 4500W | 6000W |
| MPPT Range @ Operating Voltage | 120VDC ~ 430VDC | |
| Number of Independent MPP Trackers/ Strings Per MPP Tracker | 1/1 | |
| Maximum PV Array Open Circuit Voltage | 450VDC | |
| Maximum Solar Charge Current | 80A | 100A |
| AC CHARGER | ||
| Charge Current | 60A | 80A |
| AC Input Voltage | 230 VAC | |
| Selectable Voltage Range | 170-280 VAC (For Personal Computers) ; 90-280 VAC (For Home Appliances) | |
| Frequency Range | 50Hz/60Hz (Auto sensing) | |
| PHYSICAL | ||
| Protection Degree IP20 | ||
| Dimension (W/H/D) | 330/485/135mm | 330/485/135mm |
| Net Weight | 11.5kgs | 12kgs |
| OPERATING ENVIRONMENT | ||
| Humidity | 5% to 95% Relative Humidity(Non-condensing) | |
| Altitude | <2000m | |
| Operating Temperature | 0°C - 55°C | |
| Storage Temperature | -15°C - 60°C | |
Application
| SPF 3500~5000 ES |
| Application scenarios:No power, power shortage, areas with unstable power, no shock loads such as motors |
| product features: |
| 1.Integrated MPPT charge controller. |
| 2.Equalization charging function. |
| 3.Work with battery or without battery. |
| 4.Maximum PV input voltage up to 450VDC. |
| 5.Configurable grid or solar input priority. |
| 6.Optional WIFI/ GPRS remote monitoring. |
| 7.Support parallel operation for capacity expansion up to 30kW. |
| 8.PV and Grid power the load jointly if PV energy unsu fficient. |
| 9.Flexibly schedule the Inverter charging and discharging time. |
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
Growatt Inverter 5kw Off Grid Wide Input Voltage Inverter 48v 230V with Parallel Function Solar Inverter Growatt
We recommend that users choose a suitable installation location to avoid the following situations:
1: Ambient temperature exceeds the operating range of the inverter -20 ° C ~ + 60 ° C:
2: Altitude exceeds 2000 meters;
3: humid environment;
4: Close to corrosive gas or liquid;
5: In direct sunlight;
6: Places prone to flooding or snow and ice;
7: Confined and airless place;
8: Placed with flammable materials (gas, alcohol, etc.);
9: Close to TV, communication signal tower and high voltage cable;
10: There is obstruction in 50 cm around the inverter.
