Factory Price Mortar Slurry Double Triple Food Electric Honey Allweiler Cement Molasses Dosing Screw Pump
20 Years Of Experience. Reasonable Price And Best Service, CE Certificated Products. Delivery within seven days. Please contact us for the offer.
Video
Products Description
Description:
Single screw pump is used in all fields widely to feed kind of medium, running at a constant pressure continuously, without pulse and damage when feeding medium and change the gauging aim through adjusting rotation speed. This product is applicable for feeding medium which has following properties: 1. High solid content(diameter of the biggest particle is 50mm)or no solid content 2. Medium with all viscosities(1mPas~3,000,000mPas) 3. Medium that is easy to be generated and swelled 4. Shearing sensitive medium 5. Medium with/without self lubrication 6. Erosive medium(PH=0~14) 7. Adhesive medium8. Toxicity hazard medium
|
Profile/type
|
Stainless steel food grade mono screw pump
|
||||
|
material
|
SS304 or SS316L
|
||||
|
Capacity
|
0-100T (Customized)
|
||||
|
Pressure
|
0-8bar
|
||||
|
High Viscosity
|
1-100,000,00pas
|
||||
|
Stator type
|
Rubber type
|
||||
|
temperature
|
0-80 celsius degree
|
||||
|
connection type
|
Clamp
|
Union
|
Flange
|
||
|
motor type
|
Normal
|
Ex-Proof
|
inverter
|
||
|
motor cover
|
Round/Square
|
||||
|
Speed
|
0-960RPM
|
||||
|
Technical Parameters
|
||||||||
|
Model
|
FLOW(T/H)
|
Lift(M)
|
Speed(RPM)
|
Motor(KW)
|
||||
|
ACE-10-M
|
0.5
|
0-8bar
|
1400
|
0.37
|
||||
|
ACE-15-M
|
1
|
0-8bar
|
960
|
0.55
|
||||
|
ACE-20-M
|
1.5
|
0-8bar
|
960
|
0.75
|
||||
|
ACE-25-M
|
2
|
0-8bar
|
960
|
1.1
|
||||
|
ACE-30-M
|
3
|
0-8bar
|
960
|
1.5
|
||||
|
ACE-35-M
|
5
|
0-8bar
|
960
|
2.2
|
||||
|
ACE-40-M
|
7
|
0-8bar
|
960
|
3
|
||||
|
5.5
|
0-8bar
|
720
|
2.2
|
|||||
|
ACE-45-M
|
9
|
0-8bar
|
960
|
4
|
||||
|
7
|
0-8bar
|
720
|
3
|
|||||
|
ACE-50-M
|
13
|
0-8bar
|
960
|
5.5
|
||||
|
10
|
0-8bar
|
720
|
4
|
|||||
|
ACE-55-M
|
18
|
0-8bar
|
960
|
7.5
|
||||
|
13
|
0-8bar
|
720
|
5.5
|
|||||
|
ACE-65-M
|
30
|
0-8bar
|
720
|
11
|
||||
|
ACE-85-M
|
60
|
0-8bar
|
720
|
15
|
||||
|
We Can Customize The Equipment According To Your Requirements.
|
||||||||
Application:
Screw pump rotor for food industry is also called progressive cavity pump, Is widely used in delivery of high
viscosity products such as chocolate, syrup and jams etc.
viscosity products such as chocolate, syrup and jams etc.
Details Images
1.outlet 2.pulling 3.stator 4.screw shaft 5.cardan joint 6.inlet 7.coupling 8.feeding foundation 9.feeding bid
10.bearing pedestal 11.shaft 12.auxiliary 13.bearing bid 14.shaft coupling 15.foundation 16.motor
10.bearing pedestal 11.shaft 12.auxiliary 13.bearing bid 14.shaft coupling 15.foundation 16.motor
