GOOTU One Phase Solar Inverter 10KW 8KW 7KW 6KW Dual Output Hybrid Inverter Support Lithium Battery
182380899013089_441662705_6200W1
1000 In Stock Sold Out 1000 1000 1000 1000 1000 1000 1000 1000
Share
|
Model
|
JSN-H4872E160
|
|
|
Rated Output Power
|
7200W/7200VA
|
|
|
Max. PV Input Power
|
8200W
|
|
|
Max. Solar Charging Current
|
140A
|
|
|
Grid Tie Operation
|
||
|
PV Input(DC)
|
||
|
Normal DC Voltage / Max. DC Voltage
|
360VDC/500VDC
|
|
|
Start-up Voltage / Initial Feeding Voltage
|
90VDC/120VDC
|
|
|
MPPT Voltage Range
|
90VDC~450VDC
|
|
|
Number of MPPT Tracker / Max. Input Current
|
1/27A
|
|
|
Grid Output(AC)
|
||
|
Nominal Output Voltage
|
220/230/240VAC
|
|
|
Output Voltage Range
|
195~253VAC
|
|
|
Nominal Output Current
|
31.3A
|
|
|
Power Factor
|
＞0.99
|
|
|
Feed-in Grid Frequency Range
|
49~51±1HZ
|
|
|
Efficiency
|
||
|
Max. Conversion Effeciency(DC/AC)
|
98%
|
|
|
Two Load Output Power
|
||
|
Full Load
|
7200W
|
|
|
Max. Main Load
|
7500W
|
|
|
Max. Second Load(Battery Mode)
|
2400W
|
|
|
Main Load Cut Off Voltage
|
44VDC
|
|
|
Main Load Return Voltage
|
48VDC
|
|
|
Off Grid Operation
|
||
|
AC Input
|
||
|
AC Start-up Voltage / Auto Restart Voltage
|
120-140VAC/180VAC
|
|
|
Acceptable Input Voltage Range
|
90-280VAC/170-280VAC
|
|
|
Max. AC Input Current
|
40A
|
|
|
Nominal Operatiing Frequency
|
50/60HZ
|
|
|
Super Power
|
14400W
|
|
|
PV Input(DC)
|
||
|
Max. DC Voltage
|
500VDC
|
|
|
MPPT Voltage Range
|
90VDC~450VDC
|
|
|
Number Of MPPT Tracker/Max. Input Current
|
1/27A
|
|
|
Battery Mode Output(AC)
|
||
|
Normal Output Voltage
|
48VDC
|
|
|
Output Waveform
|
Pure Sine Wave
|
|
|
Efficiency(DC to AC)
|
94%
|
|
|
Battery & Charger
|
||
|
Nominal DC Voltage
|
48VDC
|
|
|
Max. Solar Charging Current
|
160A
|
|
|
Max. AC Charging Current
|
140A
|
|
|
General
|
||
|
Physical
|
||
|
Product Dimension
|
420*310*110mm
|
|
|
Carton Dimension
|
588*463*205mm
|
|
|
Net Weight
|
14.2KGS
|
|
|
Gross Weight
|
15.7KGS
|
|
|
Interface
|
||
|
Communication Port
|
RS23/EIFI/Remove LCD /GPRS
|
|
|
Enviroment
|
||
|
Operating Temperature
|
-10~50°C
|
|
