Grid Off Inverter MTTP Hybrid Charge Controller Wind Turbine Battery 5kwh 10kwh 20kwh Solar Hybrid MTTP Inverter
Share
Empower your business with the Grid Off Inverter MTTP Hybrid Charge Controller Wind Turbine Battery 5kwh 10kwh 20kwh Solar Hybrid MTTP Inverter. This high-utility asset is meticulously selected for the Shanvis Store 2026 B2B series, offering a strategic bridge between industrial durability and commercial affordability. Engineered for marketplace resellers on Amazon, Flipkart, and Meesho, it ensures top-tier quality and logistical efficiency in the modern D2C landscape.
Grid Off Inverter MTTP Hybrid Charge Controller Wind Turbine Battery 5kwh 10kwh 20kwh Solar Hybrid MTTP Inverter
📍 Official Shanvis Store B2B Procurement Series | Version 17.0 FLAWLESS
🔍 1. Professional Product Overview
The Grid Off Inverter MTTP Hybrid Charge Controller Wind Turbine Battery 5kwh 10kwh 20kwh Solar Hybrid MTTP Inverter is a high-utility asset meticulously selected for the Shanvis Store 2026 collection. Engineered to bridge the gap between industrial reliability and commercial affordability, this product is a cornerstone for D2C brands and B2B resellers looking to establish market dominance through quality-vetted inventory.
📦 2. Comprehensive Detailed Description & Technical Specifications
MPPT Wind MTTP Hybrid Charge Controller 40 Amp Negative Grounded Controller with LCD Display, 12V/24V/48V DC Input Solar Panel Regulator for Gel Sealed Flooded and Lithium Battery Off Grid Controller Wind Turbine Solar Hybrid MPPT Charge Boost Controller with Unloader Suitable for Wind Generator Solar Panel System Controller Max 5000W
This is a multi-function inverter/charger, combining functions of inverter, MPPT50A/80A solar charger and battery charger to offer uninterruptible power support with portable size. Its comprehensive LCD display offers user-configurable and easy-accessible button operation such as battery charging current, AC/solar charger priority, and acceptable input voltage based on different applications.
-
Rated power 1KW to 5KW
-
Pure sine wave output
-
Smart LCD setting (Working modes, Charge Current, Charge Voltage, etc).
-
Bult in MPPT50A/80A solar charge controller
-
Combining solar system, AC utility, and battery power source to supply continuous power
-
Overload, short circuit and Deep discharge protection
-
Cold start function
-
Support USB, RS485 monitoring function with free CD
-
WIFI remote monitoring (optional)
-
Compatible to generator
-
3KW-5KW support parallel function(optional)
MODEL
PV18-1012 VPM
PV18-2024 VPM
PV18-3024 VPM
PV18-3048 VPM
PV18-4048 VPM
PV18-5048 VPM
Default Battery System Voltage
12VDC
24VDC
48VDC
INVERTER OUTPUT
Rated Power
1000VA/1000W
2000VA/2000W
3000VA/3000W
3000VA/4000W
4000VA/4000W
5000VA/5000W
Surge Power
2000VA
4000VA
6000VA
6000VA
8000VA
10000VA
Waveform
Pure sine wave
AC Voltage Regulation (Batt.Mode)
220VAC ~ 240VAC (Setiing)
Inverter Efficiency (Peak)
90%~93%
Transfer Time
10ms(For Personal Computers)20ms(For Home Appliance)
AC INPUT
Selectable Voltage Range
170~280VAC(For Personal Computers),90~280VAC(For Home Appliances),184~253VAC(VDE)
BATTERY
Normal voltage
12VDC
24VDC
48VDC
Floating Charge Voltage
13.7VDC
27.4VDC
54.8VDC
Overcharge Protection
150VDC
30VDC
60VDC
SOLAR CHARGER&AC CHARGER
Maximum PV Array Open Circuit Voltage
60VDC
100VDC
145VDC
PV Array MPPT Voltage Range
15~60VDC
30~80VDC
64~130VDC
Standby Power Consumption
2W
Maximum PV Array Power
625W
1250W
4000W
Maximum Solar Charge Current
50A
80A
Maximum AC Charge Current
10A or 20A
20A or 30A
60A
Maximum Charge Current
70A
80A
140A
MECHANICAL SPECIFICATIONS
Machine Dimensions (W*H*D)(mm)
272*355*100
297.5*468*125
Net Weight(kg)
7.4
14
Gross Weight(kg)
9.5
16.4
Humidity
5% to 95% Relative Humidity (Non-condensing)
Operating Temperature
0°C -55°C
Storage Temperature
-15°C -60°C
-
📦 3. What is in this Order & Packaging Information
What is in this Order:
- 1 x Grid Off Inverter MTTP Hybrid Charge Controller Wind Turbine Battery 5kwh 10kwh 20kwh Solar Hybrid MTTP Inverter
- 1 x High-Capacity Battery Pack / Power Source (If applicable)
- 1 x Fast-Charging Station & Cable (If applicable)
- 1 x Technical User Manual & Access Guide
- 1 x Secure Shanvis Store Enterprise Packaging
🚚 Packaging & Shipping Information:
Our units are shipped in multi-layered industrial-grade vibration-proof boxes. We offer Domestic and Global Shipping via our Delivered Duty Paid (DDP) model to ensure your order arrives in showroom condition directly to your warehouse.
💡 4. Strategic Importance & Business Value
In the evolving landscape of 2026 e-commerce, the Grid Off Inverter MTTP Hybrid Charge Controller Wind Turbine Battery 5kwh 10kwh 20kwh Solar Hybrid MTTP Inverter matters because it minimizes operational downtime and maximizes end-user satisfaction. For Amazon, Flipkart, and Meesho sellers, it represents a 'Hero SKU' that maintains consistent performance ratings, reducing return rates and enhancing your brand’s supply chain integrity.
🚀 5. Core Advantages & Key Features
- 🛡️ Advanced Build Integrity: Sourced using premium materials to ensure longevity in high-frequency commercial environments.
- ⚙️ Precision Functionality: Every unit is verified to meet international standards (CE/ISO equivalent) for reliable deployment.
- 💹 High ROI Potential: Low maintenance requirements paired with high-performance output ensures maximum profitability per unit.
- 📦 Fulfillment Ready: Designed with protective packaging standards suitable for global transit and Indian FBA warehouses.
📊 6. Technical Fact Sheet & Commercial Use Cases
| Series Type | Shanvis Store B2B Enterprise Line |
| Compliance | MeeThought Verified Quality Standard |
| Logistics Mode | DDP (Delivered Duty Paid) Global Shipping |
| Ideal For | Reselling, Corporate Gifting, D2C Branding, Startups |
🧾 7. Shanvis Store Trust Framework
MeeThought E-Commerce Private Limited and BHAVITHA SREE TRADING manage all customs clearance and import duties via DDP Shipping, delivering directly to your door across India.
✅ 100% GST Invoicing | ✅ Multi-State Fulfillment | ✅ Verified Low MOQ Sourcing
👍 8. Core Business Advantages (Top 10)
- Commercial Durability: Optimized build for educational and industrial use cases.
- DDP Shipping: Final landed cost certainty with no hidden import fees.
- Low MOQ Access: Low entry barriers for growing MSMEs and startups.
- Full GST Compliance: Verified B2B invoices for input tax credit claims.
- Global Quality QA: Strict multi-point checks at international source points.
- Supply Chain Stability: Reliable inventory availability for high-volume resellers.
- High Market ROI: Low overheads and consistent performance metrics.
- Fulfillment Integration: Packaging standard compatible with major Indian logistics.
- Reduced Overhead: Streamlined procurement process through official Shanvis partners.
- Verified Branding: Direct professional partnership with MeeThought/Bhavitha Sree Trading.
❓ 9. B2B Procurement FAQ
Q1: Can we claim GST Input Tax Credit?
A: Yes, we provide official B2B invoices with your GSTIN for full tax compliance.
Q2: What is the benefit of DDP Shipping for us?
A: DDP means the price you see is the final landed cost. No surprise customs or hidden duties at the time of delivery.
Q3: Is this product suitable for high-volume reselling?
A: Absolutely. We source this specifically for Amazon and Meesho power-sellers who require consistent quality.
Q4: How do you handle Quality Assurance (QA)?
A: Each batch undergoes a rigorous multi-point check at our global source facilities before dispatch.
Q5: Can we request bulk customized branding?
A: Yes, for large-scale enterprise orders, we facilitate OEM branding through our manufacturing partners.
🛡️ 10. Warranty & After-Sales Support
Shanvis Enterprise Warranty: Every unit is backed by our B2B buyer protection program. We offer comprehensive after-sales assistance, defective-on-arrival (DOA) replacements, and dedicated technical support to ensure your business operations never face unnecessary downtime.
