High Frequency parallel 5.5kw 5kw 80A hybrid solar inverter smart battery charger design HOME POWER SYSTEM kits solar inverter

Write a review

Save -49% Rs. 140,854.29 ~~Rs. 274,429.38~~

Brand : Shanvis

Collection : Home&TechAcc

SKU : 6737735013089_111573949

Availability : 9999 In Stock Sold Out 9999

HURRY ! ONLY 9999 LEFT IN STOCK.

Output Power5Kw

Inverter TypeString Inverter

ApplicationOff-Grid Solar System

Translation missing: en.products.product.product_variants

Quantity

Payment & Security

Payment methods

Your payment information is processed securely. We do not store credit card details nor have access to your credit card information.

Security

FREE SHIPPING

WORLDWIDE

BIG SAVING ON

WEEKENDS

24H SUPPORT

Description
Shipping

Overload/Over temperature/shortcircuit protection

Confgurable battery charging currentbased on applications via LCD setting

Smart battery charger design foroptimized battery performance

Model	NKH-3.5KW	NKH-5.5KW
RATED POWER	3500VA/3500W	5500VA/5500W
INPUT
Voltage	208VAC/220VAC/230VAC/240VAC
Selectable Voltage Range	170-280VAC(For Personal Computers)
Selectable Voltage Range		90-280VAC(For Home Appliances)
Frequency Range	50 Hz/60Hz(Auto sensing)
OUTPUT
AC Voltage Regulation (Batt . Mode)	208VAC/220VAC/230VAC/240VAC ±59
Surge Power	6KW	10KW
Efficiency(Peak)PV to INV	97%
Efficiency(Peak)Battery to INV	94%
Transfer Time	10 ms (For Personal Computers);20 ms (For Home Appliances)
BATTERY & AC CHARGER
Battery Voltage	24VDC	48VDC
Floating Charge Voltage	27VDC	54VDC
Overcharge Protection	33VDC	63VDC
Maximum Charge Current	100A	100A
SOLAR CHARGER
Maximum PV Array Power	1500W	5500W
MPPT Range Operating Voltage	30-115VDC	120-430VDC
Maximum PV Array Open Circuit Voltage	145VDC	450VDC
Maximum Charge Current	60A	80A
Maximum Efficiency	99%
PHYSICAL
Dimension,DWH(mm)	100300440
Net Weight(kgs)	8	9.2
Communication interface	USB/RS232/GPRS/WIFI
OPERA TING ENVIRONMENT
Mumidity	5% to 95% Relative Humidity(Non~condensing)
Operating Temperature	0°℃~ 55℃
Storage Temperature	-15°C~60°C

If You Have Other Questions, Please "Send An Inquiry".

FAQ

Q1: What is the warranty of your product?
A1: Quality warranty for 12 months; parts will be shipped free during warranty period.

Q2: Can you do OEM?
A2: Yes, we can offer the OEM service.

Q3: What is your delivery time?
A3: Within 5 day after receive advanced payment.

Q4: What minimum order do you require?
A4: 1 piece.

Q5: Why choose us?
A5: 1) Prompt delivery and good after-sale services.
2) We have our own factory, the selling prices is competitive.
3) All of our products have CE certification, ISO9001:2008, RoHS.
4) 80% new materials for production and superior quality.
5) Professional engineer designers.
