Intelligent High Performance PID Temperature Controller
Share
Promesstec Intelligent Sensor Meter Pressure Meter Sensor Indicator
Promesstec Intelligent Sensor Meter Pressure Meter Sensor Indicator
Temperature and pressure integrative intelligent digital display instrument is an upgraded product of our company, the instrument has the advantages of high measurement and control accuracy, strong anti-interference performance and so on. It has small volume, light weight, low power consumption, complete functions, reliable operation and flexible use. It can be widely used in pressure display and automatic control field of hydraulic, petroleum, chemical fiber, plastics, rubber, printing and dyeing, textile and other industries with our company's series of high temperature melt pressure transducer or room temperature industrial control pressure transducer as high accuracy pressuremeasurement and control. In addition, it can also be used in conjunction with other manufacturers' pressure transducer and temperature transducer.
|
|
Application ♦Chemical fiber Equipment ♦Plastic and Rubber manufacturing Equipment ♦Pressure Measure and Control the others melt fluid ♦Hydraulic control |
♦High measurement Accuracy ♦Good stability and repeatability ♦Strong anti-interference ability ♦Small volume, light weight, power saving, easy operation |
Technical specifications
| Display |
Double-Layer Four-Bit High Brightness LED Digital Display |
| Range |
-1999-9999 (variable decimal point) |
| Supply power |
85-265VAC, 24Vdc |
| Input signal |
1.5mV/V,2mV/V,3.33mV/V 4-20mA 0-10V |
| Output signal |
4~20mA 1-5V 0-5V0-10V,pressure upper and lower limit programmable relay alarm output,RS232, RS485serial communications |
| Repeatability |
±0.2%FS |
| Hole size |
92x46, 46x92, 92x92 |
Example of ordering
| Py 602 |
Boundary dimension |
Supply voltage |
Input signal |
Relay output |
Output signal |
PIF out |
|
|
||||||
| Empty: Square96*96 (H):Transverse 96*48 (S):Vertical 48*96 |
|
|
|
|
|
|
| (A) 24VDC, ( B ) 85-256VAC |
|
|
|
|
||
| (1 ) 2MV/V ( 2) 3MV/V (3) 0-10V (4) 4-20MA |
|
|
|
|||
| Empty: no output(I)one way relay output(II)two ways relay output |
|
|
||||
| Empty: no output (1)0-10V (2) 4-20MA |
|
|||||
| (Empty) no input (E ) E-type thermocouple (K) K-type thermocouple (J ) J-type thermocouple (PT100) PT100platinum resistor |
||||||
Changsha Luosen Automation Technology Co., Ltd. is headquartered in Changsha, Hunan, and the company is based on Promesstec. It is a technology-oriented enterprise specializing in R&D, production and sales services of A.S (automatic sensing technology). Changsha Luosen is committed to building domestic high-tech sensing technology products, combining German core sensing technology with China's localized market demand, contributing its own meager strength to the domestic sensor market, especially in the field of process automation..
Changsha Luosen's clients include Fortune 500 companies, government agencies, integrated divisions and distributors to meet the diverse market needs of manufacturing and industry. Changsha Luosen's products are mainly used in: plastic machinery, chemical fiber machinery, petrochemical, water treatment engineering, power plants, aerospace, air compressors, air conditioners, automobiles, plastics, packaging. Medical, electronics, chemical, rubber, textile and food packaging.
